Description
GRAUPNER HOTT technology. With GRAUPNER HoTT 2.4 GHz technology, the receiver has a new hopping telemetry transmission high-frequency unit with state-of-the-art components and the latest software.
The use of up to 75 channels ensures extreme operating reliability and immunity to external interference.
The receiver operates even at voltages of approx. 2.5 V. Thus, even when the batteries are getting weak ' e.g. at the end of flying time ' it remains resistant to voltage drops caused by high servo currents.
Compared to previous receivers, the sizes and weights have been reduced and the receiver input sensitivity and thus the range have been increased further.

Characteristics

• Extremely small and light
• # 33565: SH connector, #33566: ZH connector
• 6 channels or up to 8 channels with digital HoTT SUMD signal
• Internal voltage measurement or external voltage measurement up to 25.2 V with a simple voltage divider on channel 5.
• Motor connection for channel 1 for brushed motors with a maximum continuous power consumption of 2 A.
• Periods of 10 ms or 20 ms can be programmed
• 5 free mixers

Specification
Width [mm]: 12 mm
Height [mm]: 9 mm
Temperature range [°C] : - 15...+70 °C
Aerial length [mm]: 1 x Wire 30 mm
All-up weight [g]: 1,6 g
Frequency : 2400 ... 2483.5 MHz
Range approx. [m] : 300 m
Overall length [mm]: 26 mm
Dimensions [LxWxH in mm]: 26 x 12 x 9 mm
Modulation: 2.4 GHz FHSS
Current consumption [mA]: 20 mA
Operating voltage neutral [V] : (2,5) 3,6 ... 8,4 V
